Cloud control details in a nutshell



Nice and simple one here to just give all the basic summary information about your cloud control installation.

emctl status oms -details




This prompts for the sysman password, pauses for a few seconds and then returns all of this lot which gives a nice summary of the main config items of the OMS

Oracle Enterprise Manager Cloud Control 12c Release 3
Copyright (c) 1996, 2013 Oracle Corporation.  All rights reserved.
Enter Enterprise Manager Root (SYSMAN) Password :
Console Server Host        : my-oms-server
HTTP Console Port          : 7788
HTTPS Console Port         : 7802
HTTP Upload Port           : 4889
HTTPS Upload Port          : 4901
EM Instance Home           : /oracle/gc_inst12103/em/EMGC_OMS1
OMS Log Directory Location : /oracle/gc_inst12103/em/EMGC_OMS1/sysman/log
OMS is not configured with SLB or virtual hostname
Agent Upload is unlocked.
OMS Console is unlocked.
Active CA ID: 1
Console URL: https://my-oms-server:7802/em
Upload URL: https://my-oms-server:4901/empbs/upload

WLS Domain Information
Domain Name            : GCDomain
Admin Server Host      : my-oms-server
Admin Server HTTPS Port: 7103
Admin Server is RUNNING

Managed Server Information
Managed Server Instance Name: EMGC_OMS1
Managed Server Instance Host: my-oms-server
WebTier is Up
Oracle Management Server is Up


Similarly

This gives the db details for the OMS

emctl config oms -list_repos_details

Oracle Enterprise Manager Cloud Control 12c Release 3
Copyright (c) 1996, 2013 Oracle Corporation.  All rights reserved.
Repository Connect Descriptor : (DESCRIPTION=(ADDRESS_LIST=(ADDRESS=(PROTOCOL=TCP)(HOST=my-oms-server)(PORT=1524)))(CONNECT_DATA=(SID=OMSDB)))
Repository User : SYSMAN


and finally some more config settings

emctl list properties


Oracle Enterprise Manager Cloud Control 12c Release 3
Copyright (c) 1996, 2013 Oracle Corporation.  All rights reserved.
SYSMAN password:
Property Details
    Management Server : my-oms-server:4889_Management_Service
        Module = EMOMS
            em.ip.ui.enable=true
            em.jobs.ui.advanced=null
            emConfigMBeanPort=0
            em_oob_crash=false
            em_oob_shutdown=false
            em_oob_startup=false
            is_admin_server=true
            oracle.sysman.core.agent.upgradeTime=60
            oracle.sysman.core.conn.enableEncryption=TRUE
            oracle.sysman.core.conn.statementCacheSize=50
            oracle.sysman.core.dataExchange.FirstDatasetWindow=60
            oracle.sysman.core.dataExchange.IntervalBetweenMessage=2
            oracle.sysman.core.dataExchange.MaxDataPointsPerMessage=100
            oracle.sysman.core.dataservice.max_fetch_rows=2000
            oracle.sysman.core.emd.httpReadTimeout=180
            oracle.sysman.core.events.disable=false
            oracle.sysman.core.events.max_worker_threads=8
            oracle.sysman.core.events.rca.cache_size=100
            oracle.sysman.core.events.rca.enable_availabilty_rca=true
            oracle.sysman.core.events.rca.max_threads=20
            oracle.sysman.core.events.rca.trace_enabled=false
            oracle.sysman.core.events.rca.update_delay=900
            oracle.sysman.core.events.rca.wait_for_tgt_startup=10
            oracle.sysman.core.gcloader.dump_agent_list=null
            oracle.sysman.core.gcloader.max_recv_thread=20
            oracle.sysman.core.gcloader.trace_agent=null
            oracle.sysman.core.gcloader.trace_data_type=null
            oracle.sysman.core.metric.mextDeployRetryCount=25
            oracle.sysman.core.metric.propagateTargetRetryCount=25
            oracle.sysman.core.notification.cmds_per_minute=100
            oracle.sysman.core.notification.disable=false
            oracle.sysman.core.notification.email_content_transfer_encoding=8-bit
            oracle.sysman.core.notification.emails_per_connection=20
            oracle.sysman.core.notification.emails_per_minute=250
            oracle.sysman.core.notification.grace_period=null
            oracle.sysman.core.notification.grace_period_connector=null
            oracle.sysman.core.notification.grace_period_email=null
            oracle.sysman.core.notification.grace_period_java=null
            oracle.sysman.core.notification.grace_period_oscmd=null
            oracle.sysman.core.notification.grace_period_plsql=null
            oracle.sysman.core.notification.grace_period_snmp=null
            oracle.sysman.core.notification.grace_period_ticket=null
            oracle.sysman.core.notification.locale.email=null
            oracle.sysman.core.notification.locale.oscmd=null
            oracle.sysman.core.notification.locale.plsql=null
            oracle.sysman.core.notification.locale.snmp=null
            oracle.sysman.core.notification.max_delivery_threads=24
            oracle.sysman.core.notification.max_email_delivery_time=3600
            oracle.sysman.core.notification.max_java_delivery_time=86400
            oracle.sysman.core.notification.max_plsql_delivery_time=86400
            oracle.sysman.core.notification.max_snmp_delivery_time=86400
            oracle.sysman.core.notification.max_ticket_delivery_time=86400
            oracle.sysman.core.notification.minimum_grace_period=60
            oracle.sysman.core.notification.os_cmd_timeout=30
            oracle.sysman.core.notification.oscmd.max_env_var_length=512
            oracle.sysman.core.notification.parser.debug=false
            oracle.sysman.core.notification.plsql_per_minute=250
            oracle.sysman.core.notification.send_prior_status_after_agent_unreachable_clears=true
            oracle.sysman.core.notification.short_format=both
            oracle.sysman.core.notification.short_format_length=155
            oracle.sysman.core.notification.smtp.connectiontimeout=60
            oracle.sysman.core.notification.smtp.debug=false
            oracle.sysman.core.notification.smtp.timeout=180
            oracle.sysman.core.notification.snmp.max_oid_length=2160
            oracle.sysman.core.notification.snmp_packet_length=5120
            oracle.sysman.core.notification.traps_per_minute=250
            oracle.sysman.core.patch.consumer=null
            oracle.sysman.core.ping.reversePingInterval=120
            oracle.sysman.core.procedure.steplevel_graceperiod=-1
            oracle.sysman.core.procedure.use_classic_view_as_default=false
            oracle.sysman.core.security.auth.autoprovisioning=null
            oracle.sysman.core.security.auth.autoprovisioning_minimum_role=null
            oracle.sysman.core.security.auth.enable_username_mapping=null
            oracle.sysman.core.security.auth.is_external_authentication_enabled=null
            oracle.sysman.core.security.auth.ldapuserattributes_emuserattributes_mappings=null
            oracle.sysman.core.security.auth.redirect_to_canonicalUrl=false
            oracle.sysman.core.security.sso.logout_url=null
            oracle.sysman.core.security.sso.type=null
            oracle.sysman.core.serverHealthCheck.dumpModules=omsThread,repos
            oracle.sysman.core.uifwk.PublicServletEnabled=true
            oracle.sysman.core.uifwk.complianceText=null
            oracle.sysman.core.uifwk.maxRows=2000
            oracle.sysman.emRep.repositoryMode=repository
            oracle.sysman.emSDK.core.mos.mos_logout_url=https://login.oracle.com/pls/orasso/orasso.wwsso_app_admin.ls_logout
            oracle.sysman.emSDK.core.mos.mos_url=https://support.oracle.com
            oracle.sysman.emSDK.sec.DirectoryAuthenticationType=null
            oracle.sysman.emSDK.sec.Domain=null
            oracle.sysman.emSDK.sec.eus.DASHostUrl=null
            oracle.sysman.emSDK.sec.eus.Domain=null
            oracle.sysman.emSDK.svlt.ConsoleSLBUploadHTTPSPort=null
            oracle.sysman.emSDK.svlt.ConsoleServerHTTPSPort=4901
            oracle.sysman.emSDK.svlt.ConsoleServerHost=my-oms-server
            oracle.sysman.emSDK.svlt.ConsoleServerName=my-oms-server:4889_Management_Service
            oracle.sysman.emSDK.svlt.ConsoleServerPort=4889
            oracle.sysman.emSDK.svlt.EMConsoleServerHTTPSPort=7802
            oracle.sysman.emSDK.svlt.EMConsoleServerPort=7788
            oracle.sysman.emSDK.svlt.SLBEMConsoleHTTPSPort=null
            oracle.sysman.emSDK.svlt.SLBHost=null
            oracle.sysman.emas.wsmgt.http.proxyHost=null
            oracle.sysman.emas.wsmgt.http.proxyPort=null
            oracle.sysman.eml.mntr.emdRepPwdEncrypted=false
            oracle.sysman.secure.comm.EMConsoleLocked=false
            oracle.sysman.secure.comm.UploadLocked=false
        Module = LOGGING
            log4j.additivity.metricCollectionEngine=false
            log4j.appender.emlogAppender=org.apache.log4j.RollingFileAppender
            log4j.appender.emlogAppender.Append=true
            log4j.appender.emlogAppender.File=/oracle/gc_inst12103/em/EMGC_OMS1/sysman/log/emoms.log
            log4j.appender.emlogAppender.MaxFileSize=20000000
            log4j.appender.emlogAppender.Threshold=WARN
            log4j.appender.emlogAppender.layout=org.apache.log4j.PatternLayout
            log4j.appender.emlogAppender.layout.ConversionPattern=%d [%t] %-5p %c{2} %M.%L - %m

            log4j.appender.emtrcAppender=org.apache.log4j.RollingFileAppender
            log4j.appender.emtrcAppender.Append=true
            log4j.appender.emtrcAppender.File=/oracle/gc_inst12103/em/EMGC_OMS1/sysman/log/emoms.trc
            log4j.appender.emtrcAppender.MaxBackupIndex=10
            log4j.appender.emtrcAppender.MaxFileSize=5000000
            log4j.appender.emtrcAppender.layout=org.apache.log4j.PatternLayout
            log4j.appender.emtrcAppender.layout.ConversionPattern=%d [%t] %-5p %c{2} %M.%L - %m

            log4j.category.metricCollectionEngine=INHERIT
            log4j.rootCategory=WARN, emlogAppender, emtrcAppender
